EXPOSED FASTENER ROOF PANEL SYSTEMS
VERSATILITY AND FLEXIBILITY FOR YOUR ROOFING PROJECT
The TR4-36 roof profile features four 1 1/2” [38 mm] deep ribs on 9” [229mm] centers which gives an attractive, standing rib appearance. TR4-36 side laps in the high cell when used as a roof panel. All Exposed Fastener roof panels may be installed in a variety of rainscreen applications to form a complete envelope system. Systems may vary from an uninsulated screenwall to MetalWrap® Series, an insulated composite backup panel system with Advanced Thermal and Moisture Protection (ATMP®). Refer to CENTRIA Technical bulletin TB-05-10 for all rainscreen applications.
Standard:
5′ [1.52m] – 40′ [12.19m]
20’ [6.10m] max for aluminum
36” [914mm]
1-1/2” [38mm]
Smooth
Embossed
Standard:
24 – 18 gauge G-90 Galvanized Steel
Optional:
Aluminum
Stainless Steel
