The INTERCEPT+ RZR is a versatile modular metal panel system that offers a unique sloped depth in both horizontal and vertical applications, featuring concealed fastener attachment for exterior walls and soffits. These panels can range from 1-3/8” deep to a maximum of 4” deep, providing designers with flexibility in creating dynamic architectural elements. Crafted from 0.063” thick aluminum, the RZR panels ensure durability and aesthetic appeal.
With standard vertical and horizontal panel joints measuring 3/4” wide, the RZR system allows for seamless integration and a clean finish. Designers have the freedom to slope a panel’s depth across the length or width of the panels, adding a distinctive visual element to the building facade.
For enhanced design possibilities, LVLZ seamlessly integrates with INTERCEPT+ RZR and Entyre systems, enabling more dramatic plane changes and architectural creativity. The versatile system design of RZR caters to various applications, including rainscreens, uninsulated screen walls, and installation over insulated composite backup panel systems.
Prefinished aluminum INTERCEPT+ RZR panels come with a 20-year standard paint finish warranty and a 10-year anodized finish warranty, ensuring long-lasting performance and aesthetic appeal. Elevate your architectural projects with the unique design possibilities offered by INTERCEPT+ RZR.
0.063″ (1.6mm) Nominal
3/4″ (19mm)
120″ (3.0m)
Tapering depth change available starting with the Entyre and LVLZ panel dims. Depth changes occur in 1/2” increments. Panels can be sloped L-R, R-L, T-B or B-T.
Entyre 1-3/8” [35mm] to LVLZ 2” up to 4” max. [50mm to 102mm] options, 2” up to 4” max. [50mm to 102mm], 3” up to 4” max. [76mm to 102mm], 3-1/2” up to 4” max. [89mm to 102mm]
