The 3” [76 mm] depth MR3-36 provides sturdy construction which allows for longer spans and a reduction in the number of supports required. As a wall panel, MR3-36 side laps in the low cell. As a roof panel, MR3-36 is inverted and side laps in the high cell. All Exposed Fastener wall panels may be installed in a variety of rainscreen applications to form a complete wall system. Systems may vary from an uninsulated screenwall to MetalWrap® Series, an insulated composite backup panel system with Advanced Thermal and Moisture Protection (ATMP®). Refer to CENTRIA Technical bulletin TB-05-10 for all rainscreen applications.
Standard:
5 [1.524m] – 40 ft. [12.192m] Galvanized Steel
5 [1.524m] – 40 ft. [12.192m] Stainless Steel
5 [1.524m] – 20 ft. [6.096m] Aluminum Steel
Optional Length:
1 [0.305m] – 5ft. [1.524m], 40 [12.192m] – 48 ft. [14.630m] Galvanized Steel
1 [0.305m] – 5ft. [1.524m], 40 [12.192m] – 48 ft. [14.630m] Stainless Steel
1 [0.305m] – 5ft. [1.524m] Aluminum Steel
36” [914mm]
3” [76mm]
Standard: Smooth
Optional: Embossed
Standard:
20 [0.91mm], 22 [0.76mm], 24 [.60mm] Galvanized Steel
20 [0.91mm], 22 [0.76mm] Stainless Steel
0.040” [1.02mm], 0.050” [1.27mm]4 Aluminum Steel
Optional:
18 [1.19mm] Galvanized Steel
Side lap – overlapping
End Lap – Overlapping
